Download Zscaler SafeBrowser for iOS to zscaler SafeBrowser provides an easy way for corporate users to safely browse the Internet on their iOS devices. This browser guards your device. Zscaler Private Access (ZPA) is a cloud service from Zscaler that provides seamless, zero trust access to private applications running on public cloud or within the data center. With ZPA, applications are never exposed to the internet, making them completely invisible to unauthorized users.

Webinars and Live Demos. Get insight into the most topical issues around the threat landscape, cloud security, and business transformation. ‎Download apps by Zscaler Inc, including Zscaler Events, Zscaler Zenith Live, Zscaler Client Connector, and many more.

This guide will cover deployment of a Nanolog Streaming Service (NSS) VM within Azure. NSS can also be deployed on-premise using an OVA file, or in AWS.

If you’re planning to integrate with Microsoft Cloud App Security (MCAS) or Azure Sentinel, you’ll require a healthy NSS deployment, and it is highly recommended that you use Azure.

Why do I need to deploy a VM to stream logs to a SIEM? Can’t Zscaler just send logs to my SIEM directly?

Your logs are stored in Zscaler’s Nanolog clusters in a highly compressed and encoded format. The NSS VM connects to both the Nanolog cluster and the Zscaler control plane, grabs the logs, decodes them, and forwards them to your SIEM over a TCP connection. Think of NSS as a log gateway!

Be aware of potential charges

You can’t follow this guide without an Azure subscription. If you’re deploying in as part of demo or lab environment, be careful: This guide WILL rack up some charges for VM and storage resources in Azure.

If you’re using the Azure Free Account, you should have US$200 of credit to use as part of your free subscription and may be able to avoid charges.

Proceed at your own risk.

You’ll need a subscription to the NSS feature

Not all Zscaler subscriptions allow you to use NSS. In the ZIA Portal, navigate the Administration tab. If you don’t see Nanolog Streaming Service listed as an option, then you are most likely not subscribed to the NSS feature and will need to chat to your account team.

1. Log into the ZIA admin portal and navigate to Administration > Nanolog Streaming Service.
2. Select Add NSS Server
3. Give the server a name, select NSS for Web (or firewall, depending on your use case), set it to Enabled, then click Save. Activate your changes.

NSS VM System Requirements

CPU

2 vCPUs (one for the control plane, one for the data plane)

Memory

Depending upon whether this is a lab/demo or production deployment, memory requirements (and hence, the Azure instance type you deploy on) will be different. A production deployment depends on the number of users ZIA is/will be deployed to:

Note: If you are planning on integrating with Microsoft Cloud App Security (MCAS), you MUST deploy with at least 8GB of memory. Using 4GB for a Lab/Demo environment will not work.

You’ll need the following information handy to deploy NSS in Azure:

• Azure subscription (this can be the free tier - you’ll have access to US$200 credit with it which will help)
• Resource Group
• Virtual Network
• Storage Account with two containers/blobs

If you have some or all of these already, you can skip forward as needed.

1. Create an Azure Subscription

You need an Azure Subscription (even if it is part of the free tier) to continue. In the Azure Portal search bar (at the top of the page), search for “Subscriptions” and validate you have a valid subscription.

Ensure you have an existing subscription present, you click Add to create one if you need to.

Warning! You have the potential to rack up large charges if you aren’t careful! Proceed at your own risk!

2. Create a Resource Group

A Resource Group houses related resources and services for something deployed in Azure.

If you don’t have a usable Resource Group already, you’ll need to create one. In the Azure Portal search bar (at the top of the page), search for “Resource Groups'.

Click Add to create a new one. Associate it with your subscription, give it a name, and select your closest Azure region.

In the screenshot above, the Resource Group I’ll be using is called AzureLab, which is linked to the Pay-As-You-Go subscription in the Australia East region.

3. Create a Virtual Network

You’ll need (ideally) two Virtual Network (vNet) subnets to deploy NSS. In the Azure Portal search bar (at the top of the page), search for “Virtual networks'.

Click Add to create a new vNet (or select an existing one). If you’re creating a new one:

• Under the Basics tab, associate the new vNet with your subscription and resource group from above. Give it a name and ensure it’s created in the same region.
• Under the IP Addresses tab, the default 10.X.X.X/16 IPv4 address space should be fine. This will give you 65536 usable addresses in the entire vNet which is more than enough!
• There should already be a default subnet - a /24 range which will be a subset of the /16 address space above. Leave this as it is and create a new /24 subnet. One of these will be for the management interface of the NSS VM, the other for the service interface.
  • When creating a new subnet, NAT Gateway, Security Group, Route table, and Services can all be left as None or their default values for now.
• Under the Security tab, leave DDoS protection and Firewall Disabled.
• When you are finished, click Review + create.

In the image below, I have an vNet called vNetLab which has a global 10.0.0.0/16 address space; with two subnets:

• default = 10.0.0.0/24
• mgmt = 10.0.1.0/24

4. Create a Storage Account

The Storage Account will house the VHD files for our NSS VM. In the Azure Portal search bar (at the top of the page), search for “Storage accounts'.

Click Add to create a new Storage Account.

Associate the Storage Account with your existing subscription and Resource Group. Provide it with a globally unique name. Ensure the location is the same as the one associated with your Resource Group.

For the cheapest option for a lab deployment, select the following:

• Performance = Standard
• Account kind = StorageV2 (general purpose v2)
• Replication = Locally-redundant storage (LRS)
• Access tier = Hot

Under the Networking tab, for a lab/demo deployment select Public endpoint (all networks): This will ensure you can immediately connect to the storage account. For a more secure deployment (ie: production), you might want to select either of the other two options.

Under the Data Protection tab, for a lab deployment, everything should be set to Disabled.

Under the Advanced tab, for a lab deployment, set everything as Disabled.

Click Review + create when you are done.

5. Create two Blob Containers

Open the Storage Account you just created, and in the left-side-menu, select Containers. Create two containers here: one will be used to copy the VHD files from Zscaler’s storage account, and the other will be used to deploy the NSS VM itself.

These are 32GB and 500GB respectively. Zscaler makes these available on their Storage Account which you can use to copy them across to your own to avoid transfer charges (not to mention the time of downloading & re-uploading that amount of data).

In this section, we will copy the two VHD images to the Storage Account and blob containers we created earlier, and then use these to initialize the NSS VM.

1. Download Azure Storage Explorer

You can also do this via PowerShell, but that is outside the scope of this guide.

Download link (all platforms): https://azure.microsoft.com/en-us/features/storage-explorer/

2. Sign in to your Azure Account

Open Azure Storage Explorer, click the “plug” icon in the sidebar, then select Add an Azure Account. Click Next and you will be redirected to sign in to Azure via Microsoft SSO. Sign in using your Azure admin credentials.

Once you have logged in, you should see your Azure subscription in the side panel.

3. Connect to the Zscaler Storage Account

Next, we need to connect to the Zscaler Storage Account to access the NSS VHDs.

Click the plug icon again in the sidebar (as you did above), but this time select Use a shared access signature (SAS) URI.

Stop! You will need a SAS URI token from Zscaler to proceed!

You need a SAS token to authenticate with the Zscaler Storage Account. To obtain one:

• If you are a Zscaler employee, click here to visit the Community forum and obtain a token directly.
• Otherwise, you will need to raise a support ticket requesting a SAS token for NSS deployment in Azure.

Once you have your SAS token, you can fill in the fields in Azure Storage Explorer as prompted:

• Display name = ZscalerNSS
• URI = This is region dependant (see the table below), and MUST contain the SAS token as a URL argument.

For example, for deploying in Australia, my full URI would look like:

Pay close attention to the format above as it is important. If you have an issue with Azure Storage Explorer not accepting the URI, check the formatting. Do not use any of the URLs provided to you ending in.vhd.

Click Next when done, followed by Connect.

4. Error: Unable to get local issuer certificate

If you receive this error, it is most likely because your connection is being SSL inspected, and Azure Storage Explorer does not like this. You will need to add an SSL inspection bypass for .blob.core.windows.net to resolve the issue.

For ZIA, navigate to Policy > SSL Inspection in the ZIA admin portal. Add .blob.core.windows.net to the list of URLs to bypass from SSL Inspection. Save and activate your changes.

Wait a moment, then right-click on the storage account and click Refresh. If you just try and load the storage account again, you’ll continuously get the same error as it is cached.

The error should be resolved.

5. Copy the VHD files

In the side panel of Azure Storage Explorer, expand the Zscaler NSS Storage (SAS) storage account, and select the nss blob container.

Select both of the VHD images listed and click Copy.

Next, under the Azure subscription you connected to earlier, expand the storage account you created earlier and select the blob container you created to store a copy of the VHD files. Click Paste and the files will begin to transfer. This is a 532GB file transfer so it may take a minute or two.

Note: You’re now consuming storage on Azure and there is a charge associated with this. Every region is different, but using the settings I selected above, my cost was estimated to be approx US$11 per month for a single blob container. This is just for storage. Using a 2nd blob container for the VM itself PLUS VM charges will get expensive quickly; particularly for a home lab deployment. You may wish to reconsider running this in a lab environment long-term.

6. Verify the Transfer & Copy URLs

In the Azure Portal, go to your storage account and look at the blob container you transferred the VHD files to. You’ll see them listed there.

Click on each file and copy the URL listed - we’ll need these later to deploy the NSS VM.

We need to use PowerShell to deploy the NSS VM via a script.

• If you’re on a Windows device, you should have PowerShell already installed.
• If you are on Mac OS, you’ll need to install PowerShell via Homebrew.

1. Install PowerShell on Mac OS

1. Install Homebrew if you haven’t already. Open Terminal:

2. Install PowerShell:

3. Invoke PowerShell:

4. You should now be on the PowerShell prompt:

2. Install & Import the Azure Modules

These modules let us perform tasks on Azure via PowerShell:

3. Connect to your Azure account

You’ll need to sign-in and authenticate using your Azure admin credentials:

Go to https://microsoft.com/devicelogin and enter the code provided.

Return to PowerShell and press Enter/Return. After a few moments your subscriptions will appear.

4. List all VM sizes for your Azure region

We need to grab the name of the Azure instance type we’ll be deploying the NSS VM on.

You can use the Azure Pricing Calculator to determine which instance type is best (and how much it will cost you). Be sure to select your region for accurate availability and pricing. Not every instance type is available in every region.

You’ll need an instance with 2 vCPUs and either:

• 4GB memory (lab deployment)
• 8GB memory (MCAS or typical production deployment)
• 16GB memory (15K-40K users - large enterprise)
• 32GB memory (40K-100K users - huge enterprise)

If you’re not sure, just find something with 8GB of memory + 2 vCPUs.

Next, list all of the VM sizes for your selected region in PowerShell:

NB: The table above has been trimmed to fit.

Locate your desired instance, and copy down the name as it’s printed in the terminal window. We’ll need this for our PowerShell script which will deploy the NSS VM.

In my case, I’ll be using Standard_A4_v2 which has 2 vCPUs and 8GB memory.

Be very careful! VM instances become expensive over a whole month! If left on for 30 days, the Standard_A4_v2 instance type would cost be ~US$153! Proceed at your own risk!

5. Enable Compatibility Mode for AzureRM

The current Zscaler deployment script uses the old AzureRM modules which have been depreciated. We need to enable compatibility for them:

If you get an error similar to:

You’ll need to create the powershell directly under /Users/<YourUsername>/.config/:

6. (Windows) Enable Unsigned Scripts

Allow powershell to run unsigned scripts (not needed/supported on macOS):

7. Create the Deployment Config File

Copy the following into a file called conf_file.txt and replace with your data:

A description of each of these fields is below:

8. Download the Deployment Script

Download the NSS deployment script here:

Save the file as deployment_script.ps1 in the same folder as the conf_file.txt configuration file.

9. Run the Deployment Script

From the PowerShell prompt, run the deployment script. You may be prompted to sign in again:

When prompted, select the subscription to use, and (optionally) whether or not to use Public IP addresses for the two NICs. If this is a lab environment and you want to immediately be able to SSH to the NSS VM after deployment, you might want to select y for this part.

10. Verify the VM has been deployed

Check whether the NSS VM has been deployed in the Azure Portal. In the search bar at the top of the portal, search for “Virtual Machines'. Validate that your new NSS VM is present and running.

11. (Optional) Update Security Groups

If you chose to assign public IP addresses to your NSS VM during deployment, you may wish to lock this down with some rules to prevent anyone from being able to hit your VM.

As a start, you should only allow outbound connections to Zscaler’s required IP ranges. You can find these at the following URLs (depending on your Zscaler cloud):

You may also want to restrict inbound connectors to those on port 22 from your source IP only.

Apart from SSH management, NSS only requires connections to both the Zscaler Cloud and your SIEM/destination in the outbound direction. Not inbound connectivity is mandatory.

To create a security group, search for “Network security groups” in the Azure Portal. Click Add to create a new one.

You’ll need to then edit the security group, and apply it to the respective network interfaces created under the vNet in use by the VM.

For more information, see the Microsoft documentation, here.

Now that the NSS VM has been deployed, we need to configure it and associate it with our ZIA instance.

1. Connect to the VM

First, locate the IP address in use for the management interface. Under Virtual Machines in the Azure Portal, select the NSS VM, and on the Overview page, note either the Public or Private IP address assigned (under the Networking heading).

2. Review the initial NSS config

Review the NSS initial config to check whether the service interface has been configured correctly:

If the smnet_dev and Default gateway for Service IP fields are blank, check the Networking menu of the NSS VM you deployed in Azure:

Note down the private IP of the 2nd network interface <VMname>_nic_1, then run the nss configure command to set the service interface IPs:

When prompted, enter the IP address in CIDR format for the service interface (see above for formatting), and the IP address of the gateway for the service interface (if you use a /24 subnet, this will be the .1 IP address)

3. Download the SSL Certificate Package

Download the SSL Certificate package for your NSS VM from the ZIA portal under Administration > Nanolog Streaming Service.

WARNING: This package is different for each NSS VM you have listed. Sharing the same certificate between NSS deployments will cause connection flapping.

Copy this package to the NSS VM:

Install the certificate package on the NSS VM:

Check the configuration:

If the SSL package was installed correctly, you will see your cloud name referenced in the configuration (eg: zscaler.net).

4. Update the NSS Service

The NSS service on the fresh VM is probably out-of-date. To update it, run the nss update-now command:

Updating may take some time…

You can check the current version with nss checkversion:

5. Start the NSS Service

To start the NSS service, run nss start:

This will NOT start NSS on boot by default. You should enable autostart:

6. Verify Connectivity

To check active connections from NSS, run the following command:

NSS only requires outbound connectivity to the Zscaler Cloud and your SIEM/destination. No inbound connectivity is necessary (unless you’ve enabled SSH).

A healthy NSS instance will have two TCP connections in the ESTABLISHED state:

If you only see one connection, wait a few minutes and check again. If neither connection is in the ESTABLISHED state, or you are still missing a connection, check your firewall and ensure you have reachability to the Zscaler infrastructure. You can check the network requirements for NSS using the links below (select the link corresponding to the Zscaler cloud you have been provisioned on):

Return to the ZIA portal, and under Administration > Nanolog Streaming Service, the NSS instance you just deployed should now read as Healthy:

Zscaler App Install

NSS Feeds configured in the ZIA portal explicitly tell your NSS VM instance what data to stream, where to stream it, and in what format it is required.

Each NSS VM can be configured with up to 8 data feeds.

1. Configure an NSS Feed

To configure an NSS Feed, go to Administration > Nanolog Streaming Service, then select the NSS Feeds tab. Click Add NSS Feed.

Fill in the following data when prompted:

Click Save when you are done and activate your changes.

Note that Zscaler has formal partnerships with several SIEM vendors, and in many cases has co-written deployment guides for them. If you don’t see your SIEM listed in the Feed Output Type, check to see if they don’t already have an article on Zscaler integration. Failing that, odds are they can probably ingest one of the existing formats; like QRadar LEEF, or Arcsight CEF.

Zscaler documentation covers how to configure feeds for a variety of features:

2. Configuring MCAS

If you’re looking to integrate with Microsoft Cloud App Security (MCAS), I’ve written a detailed guide here.

Download Zscaler App

You should now have a healthy NSS deployment in Azure.

Zscaler For Mac Download

If you deployed this for lab or demo purposes, make sure you don’t forget about the running NSS VM! Ensure you stop and de-allocate resources after you’re done so you don’t continue to be charged.
