To download a copy of a product’s manual please enter the exact model number for your Champion Power Equipment product. Your product’s model number: Due to a record-breaking hurricane season amidst the ongoing pandemic, call volume & wait time are longer than normal. For self-service support visit our Help Center. The Green Industry News presents Richard Daigle with Irrigator Technical Training School as he goes in depth explaination of the maintenance of Champion Valves.

  • Champion 200RS-100 1' in. Manual Angle Valve Yellow Brass without Union with Rising Swivel. Champion Valves can provide you with a professional irrigation installation without the need of the professional. Saving money on pipe is a big desire of most irrigation installers.
  • CHAMPION IRRIGATION PD RK-2C Valve Stem Gasket Repair Kit, 1-Inch. Save 25% on 3 select item(s) FREE Shipping. Other options New from $12.00. Storm Drain FSD-120-6 6-in. Deep Riser Sprinkler Valve Box. 4.9 out of 5 stars 14.
Champion Straight & Angle Manual Valves are made from high-quality brass and are available in 3/4', 1', 1-1/4', 1-1/2' & 2' sizes. Straight valves effectively regulate water supply for irrigation use with full size water ways for low pressure loss. Straight valves can be converted to automatic operation with an add-on actuator. Angle valves are available in standard floating washer or the 'RS' models, which feature a rising swivel seat washer.
  • 100RS Series Brass Manual Straight Valves
    More
  • 200RS Series Brass Manual Straight Valves
    More
  • 300 Series Brass Manual Angle Valves with outlet Union
    More
  • 300RS Series Brass Manual Straight Valves with Outlet Union
    More

6 Item(s)

Manual

Great news!

Champion Sprinkler Valve Parts

If your sprinkler timer has failed, or there is an issue with the wiring, it is still possible to turn on the sprinkler zone manually, by opening the valve with your hands.

This way you don’t have to run back and forth between the timer/controller and the zone you are watering.

Opening the valve manually is very useful if you are checking out a sprinkler system. This is because you can open a sprinkler valve without using the sprinkler timer. This is a huge time saver, especially if the timer happens to be in the basement, in the garage, or another room in the house. This way you don’t have to run back and forth between the timer/controller and the zone you are watering. If you have multiple valves in a manifold, you can open them all in a single location.

There are 2 simple methods to open the valve manually:

1. Open the Manual Bleed Screw

The first way to open this valve is to open the manual bleed screw. You will notice that the manual bleed screw is located towards the back of the valve near the flow control. To open the valve manually, twist the manual bleed screw counter-clockwise until the valve opens. It usually doesn’t need to be more than one-half turn. To close the valve turn the manual bleed screw clockwise until the valve closes. Note: opening the manual bleed screw will cause water to leak out, this is normal, and there is no reason to be alarmed.

ManualChampion Sprinkler Valve ManualChampion sprinkler valve repair

2. Turn the Solenoid

Champion Superior Sprinkler Valve Manual

The second way to open the valve is to grasp the solenoid (the black cylinder with the wires attached to it) and turn it approximately one-quarter turn counter-clockwise until the valve opens. To close the valve, turn the solenoid clockwise until the valve closes. This is the method that many prefer because most times when you open the manual bleed screw, it causes water to leak out into the valve box. If the valve is left on for any period of time, it can start filling the valve box with water. Usually opening the valve by twisting the solenoid doesn’t leak water into the valve box.

Champion Sprinkler Valve Manual Override

So the next time your sprinkler system is not working correctly, and you need to apply water, try operating the zone valve manually.

Champion Sprinkler Valve Manual

Happy sprinkling!
